Advantages and Disadvantages
Advantages
- Supports IEEE802.3at and IEEE802.3af standards.
- High total power output of 120W.
- Flexible mode selection with DIP switch.
Disadvantages
- Limited to 10/100M speeds.
- May require ventilation to prevent overheating.
- Relative humidity restrictions.
Ask a Question
Frequently Asked Questions
The Cudy Desktop Switch FS1010P has a total power output of 120W, which is sufficient to power multiple PoE devices like IP cameras and wireless access points.
Is this answer helpful?
No, the Cudy Desktop Switch FS1010P supports 10/100M speeds, which is adequate for most home and small business applications but does not support gigabit speeds.
Is this answer helpful?
The switch is designed to operate in temperatures ranging from -20 to 50℃. For storage, it can withstand temperatures from -40 to 80℃.
Is this answer helpful?
The FS1010P features a DIP switch that allows you to easily switch between standard, VLAN, and link extension modes, making it flexible for various network configurations.
Is this answer helpful?
Yes, the switch supports a working height of up to 10,000 feet (3,000 meters), making it suitable for high-altitude installations.
Is this answer helpful?
The FS1010P has a MAC address table capacity of 1K, which is sufficient for most small to medium-sized network environments.
Is this answer helpful?
For technical support, you can reach out to Cudy via email at [email protected]. Additional resources and documentation are available on their website at www.cudy.com.
Is this answer helpful?
Product Description
Cudy Desktop Switch: A Comprehensive Guide to the FS1010P 8-Port PoE+ Switch
The Cudy Desktop Switch FS1010P is a versatile and robust 8-Port 10/100M PoE+ Switch with 2 Uplink Ports, designed to meet the needs of both home and small business networks. This switch stands out with its adherence to multiple IEEE standards, including IEEE802.3 and IEEE802.3af/at, ensuring compatibility with a wide range of devices.
Key Features
One of the main features of the Cudy Desktop Switch is its Power over Ethernet (PoE) capability. It supports IEEE802.3at (30W) and IEEE802.3af (15.4W) standards, making it ideal for powering devices such as IP cameras, VoIP phones, and wireless access points. The switch delivers DC 52V power over spare pairs 1/2(+) and 3/6(-), ensuring efficient power distribution.
The switch is built for performance with a total power output of 120W and a bandwidth capacity of 2Gbps. It operates using a Store-And-Forward forwarding mode, which ensures data is verified before forwarding, thus maintaining network integrity.
Specifications
The FS1010P is designed to operate in a wide range of environmental conditions, with a working temperature range of -20 to 50℃ and a storage temperature range of -40 to 80℃. It also supports a working height of up to 10,000 feet (3,000 meters), making it versatile for different deployment scenarios.
Physical Design
The switch measures 200mm in length, 120mm in width, and 45mm in height, making it compact enough for desktop use while still providing ample connectivity options. The LED indicators on the device provide clear status updates, including power, link activity, and port isolation.
Installation and Configuration
Setting up the FS1010P is straightforward, thanks to its intuitive design and the detailed Cudy Desktop Switch Manual. The switch features a DIP switch for easy mode selection, allowing users to switch between standard, VLAN, and link extension modes. This flexibility makes it easy to tailor the network to specific needs, whether it’s for high-speed data transfer or extended PoE transmission.
Notes
- The switch supports a maximum relative humidity of 90% (non-condensing) during operation and 95% during storage.
- For optimal performance, ensure the device is installed in a well-ventilated area to prevent overheating.
Conclusion
The Cudy Desktop Switch FS1010P is a reliable and efficient networking solution that offers a range of features to support various network configurations. Its PoE capabilities, combined with its robust design and ease of use, make it an excellent choice for both home and small business networks. \nNo reviews available to analyze.
